Transform your construction projects with our precise and comprehensive 3D BIM modelling solutions at Praniv Enspan – reinforcement detailing, BS 8666 bar bending schedules and automated rebar modelling in Revit.
From raft foundations and pile caps to column cages, core walls, slab mats, precast and post-tensioned elements – every bar is modelled in 3D, scheduled to BS 8666 or any code you need, and ready for site. Click a photo to enlarge.
Site photographs are representative images (Unsplash licence). Project-specific models and drawings are shared with clients under NDA.
Delivered for major UK infrastructure, commercial and residential projects. Project names are withheld under client confidentiality agreements.
Dynamo/Revit tools that model BS 8666 reinforcement element by element – pile caps, slabs, beams, columns and walls – directly on IFC concrete, Revit 2022–2026.
BS 8666:2020 schedules generated from Revit and IFC exports, with a full shape-code library, automatic validation, coupler handling and fabric mesh / wastage schedules.
Nine automated model checks – bar-mark format, length rounding, cover, 3D clashes, laps and couplers, tonnage per drawing – reported to Excel for sign-off.
Plans, elevations and sections created automatically from the 3D rebar model, with bar-mark annotation, bending schedules on sheet and DWG export.
Tendon layouts from PT design software converted into Revit ducts, live/dead/pan anchorages and bursting spirals for full coordination.
Precast stairs and lattice (plank) slabs – centre-of-gravity checks, lifting-loop placement and automated production output.
Rebar property sets mapped for IFC and Bentley iDGN delivery – bar marks, shape codes, weights, grades and coupler data filled automatically.
Basement drainage recesses and slab thickenings generated from DXF setting-out, so reinforcement is detailed around the real geometry.
Every drawing is tracked in our in-house portal – detailer/checker workflow, signed checklists, input and RFI registers, transmittals and a lessons-learnt log – so issues are traceable and on time.
Send us your drawings, scope or questions. Your enquiry goes straight to our team and we usually reply within one working day.
